Product Features
1. It can perform high-speed drag welding, spot welding, oblique welding, shake welding, etc. on various workpieces.
2. There are functions for copying solder joint arrays and parameters.
3. Cleaning steps can be inserted in the middle of the program, and steps such as skipping and flipping fixtures can be set.
4. Unique welding product name settings, making the search more intuitive.
5. Multi level password protection function, authorized separately by operators and technicians.
6. Communication between multiple machines, program copying to each other, saving time for repetitive program editing.
7. The program has individual calibration and overall calibration functions, which can achieve overall translation calibration or partial point calibration of the workpiece.
8. Single step automatic positioning function, convenient for program development.
9. The program storage capacity can reach up to 999 sets, 9999 points per set, and can be increased according to customer requirements.
10. It has insertion and deletion functions, making it easy to quickly modify and create programs.
11. The fully Chinese user-friendly interface dynamically displays running coordinates, welding cycle, output, product name, and intuitive parameter settings.
Product parameters
Model DHS-5441R Action speed XYZ axis: 0-600mm/s R axis 0-600 degrees S
Tin feeding device with adjustable wire diameter and memory capacity of 999 sets and 9999 points per set (infinitely expandable)
The minimum analysis degree of the DSP controller in the control system is 0.01mm
Temperature control device dual high-frequency eddy current type/0-520 ℃ adjustable repeatability accuracy ± 0.02mm
Iron tip cleaning air blowing power consumption starts at 380W and runs normally at 180W
Special soldering iron tip 200W, air pressure 5kg/cm2
Welding angle 0-180 degrees, suitable for tin wire ￠ 0.3mm~￠ 1.6mm
