Product Features
Fully automatic electric screwdriver, when the screw is locked to the set torque, the clutch will automatically escape, the motor will automatically power off and brake in time, causing the electric screwdriver to stop running.
Adopting a brushless aerospace grade motor, it does not generate dust, has low noise, durability, and does not require maintenance.
Adopting a contactless switch, there is no need to replace consumables, and it has a long service life.
The forward/reverse switch conforms to the dimensions of ergonomics and can be operated with one hand. The torque adjustment is infinitely adjustable by rotating the torque adjustment ring left and right.
All functional electrical interfaces of this electric screwdriver are plug-in structures, and subsequent maintenance does not require a soldering iron. The lightning source board, main control board, brake board, starter board, positive and negative opening board, including the motor and clutch assembly, that need to be replaced can be manually unplugged and replaced in seconds, effectively improving maintenance rates and reducing maintenance costs.
Product parameters
model | Model number | Startup method | Range of torque | Standard speed | Adjustable speed without segments | Length (ground surface) | weight（克） | Applicable screws（mm） | Suitable for screwdriver heads |
D-2410 | Standard speed | Hand press type | 1—10 | 1000 | 850-1100 | 246 | 515 | 2.0-3.0 | ?5,S5 |
D-2416 | Hand press type | 2—16 | 1000 | 850-1100 | 246 | 515 | 2.0-4.0 | ?5,S5 | |
D-2420 | Hand press type | 3—20 | 1000 | 850-1100 | 246 | 515 | 2.0-5.0 | ?5,S5 | |
D-2425 | Hand press type | 4—25 | 1000 | 850-1100 | 246 | 515 | 2.0-5.0 | ?5,S5 | |
D-2410 | high speed | Hand press type | 1—10 | 1000 | 1350-1700 | 246 | 515 | 2.0-3.0 | ?5,S5 |
D-2415 | Hand press type | 1.5—15 | 2000 | 1350-1700 | 246 | 515 | 2.0-4.0 | ?5,S5 |
